Sigma 2 SG800
Sigma 2 SG800 (7-Stage Edge Banding Machine)
A heavy-duty 7-stage edge banding machine with dual independent motors for line and corner trimming, automatic up/down movement, and a Delta touchscreen. Built for continuous, high-precision production runs.
Request a QuoteTechnical Specifications
- Dimensions
- 5900 × 820 × 1250 mm (L×H×W)
- Weight (approx.)
- 2000 kg
- Total Power
- 13.8 kW
- Air Pressure
- 0.6 – 0.8 MPa
- Panel Thickness
- 10 – 50 mm
- Glue Pot Capacity
- 1.5 – 2 L
- Edge Strip Thickness
- 0.4 – 3 mm max
- Feed Speed
- 11 / 14 / 20 m/min
Processing Stages
- 1Panel edge trimming unit
- 2End cutting unit
- 3Line trimming unit (two independent motors)
- 4Tillable trimming unit (two independent motors)
- 5Rounding unit
- 6Edge & glue scraping unit
- 7Brushing unit
Advanced Features
- ✓Delta touchscreen
- ✓Manual lubricator
- ✓Automatic up and down movement
- ✓Meter counter
