Sigma 3 E-05L
Sigma 3 E-05L (Edge Banding Machine)
A streamlined edge banding machine handling end cutting, trimming, glue scraping, and brushing, with automatic lubrication and a Schneider-based control system.
Request a QuoteTechnical Specifications
- Dimensions
- 4200 × 600 × 1800 mm (L×H×W)
- Weight (approx.)
- 1250 kg
- Total Power
- 8 kW
- Air Pressure
- 0.6 MPa
- Panel Thickness
- 10 – 60 mm
- Glue Pot Capacity
- 1.5 – 2 L
- Edge Strip Thickness
- 0.4 – 3 mm
- Feed Speed
- 15 – 23 m/min
Processing Stages
- 1End cutting unit
- 2Line & tillable trimming unit
- 3Edge & glue scraping unit
- 4Brushing unit
Advanced Features
- ✓Auto lubrication
- ✓Automatic up and down movement
- ✓Meter counter
- ✓Cleaning liquid at the end
- ✓PLC & Delta touchscreen
- ✓Schneider control system
